Chief LSA1U Large Fusion® Fixed Wall Display Mount

Chief

Fusion® Wall-Fixed Series Series

The Chief LSA1U is a part of the Fusion® Wall-Fixed Series and is designed using direct installer feedback to provide a stable, low-profile, and efficient mounting solution for large flat panel displays. Supporting screens from 42" to 86", the LSA1U includes key Fusion® features such as Centerless Shift™, ControlZone™ leveling adjustment, and ClickConnect™ latching—alongside enhancements in cable management, installation speed, and equipment security.

Highlighted Features

  • Integrated Teardrop Design: Speeds up wall plate installation by allowing pre-installation of bolts to the wall.
  • Centerless Shift™: Provides post-installation lateral shift for limitless display centering.
  • Set Screws: Ensure the mount remains rigid and secure over time.
  • ClickConnect™: Provides an audible click to confirm the display is securely attached.
  • Built-in Cable Stand: Enables easy access under the screen for streamlined cable management.
  • Accessory Compatibility: Supports a full line of accessories that can be installed with the mount.
  • Flexible Stud Mounting: Compatible with 16" to 32" stud distances, providing installation versatility.
  • Nesting Spacers: Stackable to allow custom depth configurations.
  • Quick-Store Cords: Use magnetic storage to keep pull cords neat and accessible.
  • Improved Cable Management: End caps allow for better cable routing and a cleaner look.
  • Integrated Security: Helps safeguard displays in shared or public spaces.
  • Staged Installation Support: Ships with a custom hardware kit that can hang from mount rails during staged installations.
  • Eco-Friendly Packaging: Ships in an easy-open box with less packaging waste.

The Chief LSA1U is an ideal fixed wall mounting system for AV professionals looking to install large displays in commercial, educational, or collaborative environments. With refined installer-centric features and superior stability, it ensures both performance and ease of use.

In stock
£124.52

Secure Checkout

Warranty Protection

Hassle-Free Returns

The Chief LSA1U is a part of the Fusion® Wall-Fixed Series and is designed using direct installer feedback to provide a stable, low-profile, and efficient mounting solution for large flat panel displays. Supporting screens from 42" to 86", the LSA1U includes key Fusion® features such as Centerless Shift™, ControlZone™ leveling adjustment, and ClickConnect™ latching—alongside enhancements in cable management, installation speed, and equipment security.

Key Features

  • Integrated Teardrop Design: Speeds up wall plate installation by allowing pre-installation of bolts to the wall.
  • Centerless Shift™: Provides post-installation lateral shift for limitless display centering.
  • Set Screws: Ensure the mount remains rigid and secure over time.
  • ClickConnect™: Provides an audible click to confirm the display is securely attached.
  • Built-in Cable Stand: Enables easy access under the screen for streamlined cable management.
  • Accessory Compatibility: Supports a full line of accessories that can be installed with the mount.
  • Flexible Stud Mounting: Compatible with 16" to 32" stud distances, providing installation versatility.
  • Nesting Spacers: Stackable to allow custom depth configurations.
  • Quick-Store Cords: Use magnetic storage to keep pull cords neat and accessible.
  • Improved Cable Management: End caps allow for better cable routing and a cleaner look.
  • Integrated Security: Helps safeguard displays in shared or public spaces.
  • Staged Installation Support: Ships with a custom hardware kit that can hang from mount rails during staged installations.
  • Eco-Friendly Packaging: Ships in an easy-open box with less packaging waste.

Specifications

Model LSA1U
Typical Screen Size 42" - 86" (1067 mm - 2184 mm)
Depth 2" (5.08 cm)
Height 20.5" (52.07 cm)
Width 34.8" (88.26 cm)
Overall Dimensions 20.50 x 34.75 x 2" (521 x 883 x 51 mm)
Lateral Shift 17.4" (441 mm)
Shipping Weight 7 lbs (3.18 kg)
Wall Stud Compatibility 16" - 32" (406 mm - 813 mm)
Weight Capacity 200 lbs (90.7 kg)
Orientation Landscape
Adjustability Fixed, Lateral Shift
Application Wall
Color Black
Solution Type Universal
VESA Mounting Pattern 100 x 100 mm – 870 x 500 mm
Certifications OSHPD, TUV, UL Listed

The Chief LSA1U is an ideal fixed wall mounting system for AV professionals looking to install large displays in commercial, educational, or collaborative environments. With refined installer-centric features and superior stability, it ensures both performance and ease of use.
