SKU: DGE-1000

Crestron DGE-1000

Crestron

Digital Graphics Engine 1000

The Crestron DGE-1000 Digital Graphics Engine is a cutting-edge solution that transforms an HD touch screen display into an advanced Crestron control system. Powered by Crestron HTML5 technology, it delivers a highly customizable and intuitive graphical interface for controlling audio, video, lighting, shades, HVAC, security, and other systems. Ideal for dual-window video display and web browsing, the DGE-1000 is compact and designed for discreet installation behind displays, under tables, or inside lecterns and equipment racks.

Highlighted Features

  • Touch Screen Interface: Compatible with the TSD-2220 HD touch screen display and third-party USB HID touch screens, offering advanced control and customization.
  • Crestron HTML5 Technology: Enables the creation of custom graphical environments for intuitive and interactive control solutions.
  • HD Streaming Video: Supports H.264, H.265, and MJPEG formats for high-definition streaming from IP cameras, encoders, and other sources.
  • HDMI® Input and Output: Connects high-definition video sources, including AirMedia® wireless gateways, with output resolutions up to 3840x2160@60Hz (2160p60).
  • Onboard Control Ports: Built-in RS-232, IR, and Ethernet ports allow for comprehensive device control, while HDMI CEC simplifies connectivity.
  • Crestron Home® OS Support: Fully integrates with Crestron Home OS for seamless control of lighting, shades, climate, media, security, and more.
  • Enterprise-Grade Security: Features 802.1X authentication, TLS encryption, and Active Directory® integration for robust networking and secure operation.
  • XiO Cloud® Compatibility: Enables remote provisioning, monitoring, and management for enterprise-wide deployments.
  • Compact Installation: Designed for surface mounting behind displays or under tables for clean and space-efficient setups.

The Crestron DGE-1000 provides a versatile and high-performance platform for control, collaboration, and interactive solutions. Its advanced features, enterprise-grade security, and scalable integration make it an essential component for professional, residential, and government environments.

In stock
£1,892.40

Secure checkout

Friendly support

Hassle-free returns

The Crestron DGE-1000 is an advanced digital graphics engine that transforms HD touch screen displays into sophisticated Crestron controllers. With support for Crestron HTML5 technology, it enables custom graphical environments for managing audio, video, lighting, shades, HVAC, security, and other system features. The DGE-1000 is ideal for dual-window video display, web browsing, and more. Its compact, surface-mountable design allows for discreet installation behind displays, under tables, or within equipment racks.

Key Features

  • HTML5 Technology: Utilises Crestron HTML5 User Interface for creating advanced control environments.
  • Touch Screen Compatibility: Works with TSD-2220 HD touch screens and third-party USB HID-compliant touch screens.
  • HD Streaming Video: Displays high-definition video from IP cameras and streaming encoders (H.264, H.265, and MJPEG supported).
  • Dual HDMI Support: Includes HDMI input and output, supporting up to 3840x2160@60Hz resolutions.
  • Built-In Web Browser: Provides access to online resources and device control interfaces.
  • Low-Profile Installation: Surface-mountable, fits behind displays or inside lecterns for clean setups.
  • Enterprise-Grade Security: Includes TLS encryption, HTTPS connectivity, and Active Directory® integration.
  • Crestron Home® OS: Seamlessly integrates with Crestron Home solutions for managing lighting, media, and more.

Specifications

Graphics Engine Crestron HTML5 technology, dual video windowing, web browser, and multilingual annotation
Languages Supports multilingual keyboard and web browsing
Video Input/Output Input: HDMI (DVI and dual-mode DisplayPort™ compatible), resolutions up to 1920x1080@60Hz (HD 1080p60)
Output: HDMI (DVI compatible), resolutions up to 3840x2160@60Hz (2160p60)
Input Resolutions HDMI Input: 1920x1080@60Hz (HD 1080p60); Note: Interlaced video is not supported. All video inputs will be scaled to the selected HDMI.
Output Resolutions 1280x720@50Hz (720p50), 1280x720@60Hz (720p60), 1280x800@60Hz1, 1366x768@60Hz1, 1440x900@60Hz1, 1600x900@60Hz2, 1600x1200@60Hz, 1680x1050@60Hz2, 1920x1080@50Hz (1080p50), 1920x1080@60Hz (1080p60), 3840x2160@30Hz (2160p30), 3840x2160@50Hz (2160p50), 3840x2160@60Hz (2160p60).[1 The output resolution is with or without reduced blanking; 2 The output resolution is with reduced blanking only.]
Note: All video inputs are scaled to the selected HDMI output resolution.
Streaming Decoder H.264, H.265, AAC stereo, up to 25 Mbps, up to 1080p30
Audio HDMI input/output, 2-channel LPCM
Connectivity Ethernet, HDMI, RS-232, IR/serial, USB 2.0 and 3.0 HID, and PoE+
Power Powered via PoE+ or optional power pack (14 W typical consumption)
Environmental Temperature: 32°F to 104°F (0°C to 40°C)
Humidity: 10% to 90% RH (non-condensing)
Heat Dissipation: 47.8 BTU/hr
Dimensions Height: 1.26 in. (33 mm)
Width: 7.40 in. (188 mm)
Depth: 6.54 in. (166 mm)
Weight 1.9 lb (0.86 kg)

The Crestron DGE-1000 offers robust performance, advanced functionality, and secure networking to meet modern control and collaboration needs. Ideal for home, corporate, and government applications, its flexible design ensures a seamless integration into any environment.
