Hikvision DS-D2046TL-2B 46" 2.5mm LCD Video Wall Display

SKU: DS-D2046TL-2B

Hikvision DS-D2046TL-2B 46" 2.5mm LCD Video Wall Display

Name: Hikvision DS-D2046TL-2B 46" 2.5mm LCD Video Wall Display
Brand: Hikvision
SKU: DS-D2046TL-2B
Price: 1267.22 GBP
Availability: InStock

Hikvision

46" 2.5mm LCD Video Wall Display

The Hikvision DS-D2046TL-2B 46" 2.5mm LCD Video Wall Display (DS-D2046TL-2B) delivers 1920×1080 Full HD content across a 46-inch VA LCD with a 2.5mm ultra-narrow physical seam for tight video wall tiling. Direct-lit LED at 500cd/m² with factory-calibrated colour and brightness uniformity ensures consistent imagery across looped arrays of up to 30 screens via HDMI. VGA, HDMI, DVI, and DP inputs with HDMI output and RS-232 in/out integrate into any video wall and AV control system.

Highlighted Features

2.5mm Ultra-Narrow Seam: 2.5mm physical seam (±0.8mm) for tight video wall tiling with minimal visible gaps -- ideal for control rooms and image walls
500cd/m² Direct-Lit LED: 500cd/m² direct-lit LED with no boundary shadows -- ideal for bright retail and corporate environments
Factory Calibrated Uniformity: Factory colour and brightness calibration ensures consistent output across all panels in a multi-display array
4K Input, Loop to 30 Screens: Accepts 4K signal and auto-loops to 30 screens for large video wall networks
VGA, HDMI, DVI, DP + RS-232: Comprehensive input set with serial control for full AV system integration

The Hikvision DS-D2046TL-2B 46" 2.5mm LCD Video Wall Display is the ideal solution for professional video wall installations in control rooms, corporate lobbies, and public venues requiring ultra-narrow bezel tiling and reliable 24-hour operation.

In stock

£1,267.22

Secure Checkout

Warranty Protection

Hassle-Free Returns

The Hikvision DS-D2046TL-2B 46" 2.5mm LCD Video Wall Display provides a professional building block for video wall installations with a 2.5mm ultra-narrow seam and factory-calibrated colour and brightness uniformity. The 46-inch VA panel at 500cd/m² loops to arrays of up to 30 displays, and VGA/HDMI/DVI/DP inputs with RS-232 in/out complete the integration package.

Key Features

2.5mm Seam: 2.5mm physical seam (±0.8mm) for near-seamless video wall configurations
500cd/m² Direct-Lit LED: Uniform brightness across the full panel with no boundary shadows
Factory Calibration: Matched colour and brightness across all panels in a looped array
4K Input, 30-Screen Loop: 4K HDMI input with auto-loop to 30 displays
VA Panel, 1200:1: 1200:1 contrast, 8.5ms, 8-bit/16.7M, 178° viewing
Metal Casing, EMC Shielded: Professional durability for 24-hour continuous operation

Specifications

Screen	46" VA
Resolution	1920×1080
Physical Seam	2.5mm (±0.8mm)
Brightness	500cd/m²
Contrast	1200:1
Response	8.5ms
Inputs	VGA×1, HDMI×1, DVI×1, DP×1, USB×1
Output	HDMI×1
Control	RS-232 IN/OUT
Power	100–240VAC, ≤200W
VESA	600×400mm
Dims	1020.91×575.44×47.95mm
Weight	10.6kg

What's in the Box

LCD display × 1
Power cable × 1
Network cable × 1
2m HDMI cable × 1
Screw × 4
Remote control × 1
IR receiver × 1
RS-232 converter × 1
Quick start guide (multilingual) × 1
Quick start guide (English) × 1
LCD Maintenance Notice × 1

Warranty

The Hikvision DS-D2046TL-2B 46" 2.5mm LCD Video Wall Display is backed by the 3-year manufacturer warranty, providing peace of mind for professional installations.

Application Examples

Control Room Video Walls	Multi-panel CCTV and operations monitoring with 2.5mm seams
Corporate Lobby Displays	Brand content walls and information displays in corporate receptions
Retail Visual Merchandising	Product video and campaign walls in retail flagships
