The Hikvision DS-D2065LU-Y 65" 3.5mm 4K LCD Video Wall Display brings full 4K resolution to tiled video wall installations with a 3.5mm narrow seam. The 3840×2160 panel with direct-lit LED at 500cd/m² and factory-calibrated uniformity delivers consistent 4K content across looped arrays, and six picture modes allow optimisation for different content types.

Key Features

  • 65" 4K, 3.5mm Seam: 3840×2160 at 500cd/m², 1200:1, 10ms, 72% NTSC; 3.5mm seam (2.3mm top/left, 1.2mm bottom/right)
  • Six Picture Modes: Standard, meeting, movie, monitoring, text, and user-defined modes
  • 4K Input, 30-Screen Loop: 4K HDMI auto-loop to 30 displays
  • HDMI, DVI, VGA, DP: Comprehensive inputs with HDMI output and RS-232 in/out
  • SECC Metal Casing: Structural rigidity and EMC protection for 24-hour operation

Specifications

Screen 65" SECC
Resolution 3840×2160@60Hz
Physical Seam 3.5mm (2.3/1.2mm)
Brightness 500cd/m²
Contrast 1200:1
Response 10ms
Active Area 1428.48×803.52mm
Inputs HDMI×1, DVI×1, VGA×1, DP×1
Output HDMI×1
Control RS-232 IN/OUT
Power 100–240VAC, ≤260W
VESA 800×600mm
Dims 1432.58×807.62×85.1mm
Weight 29.2kg

What's in the Box

  • LCD display × 1
  • Power cable × 1
  • Network cable × 1
  • 2m HDMI cable × 1
  • Screw × 4
  • Remote control × 1
  • IR receiver × 1
  • RS-232 converter × 1
  • Quick start guide (multilingual) × 1
  • Quick start guide (English) × 1
  • LCD Maintenance Notice × 1

Warranty

The Hikvision DS-D2065LU-Y 65" 3.5mm 4K LCD Video Wall Display is backed by the 3-year manufacturer warranty, providing peace of mind for professional installations.

Application Examples

Corporate Boardrooms 4K feature walls for executive boardrooms requiring premium resolution content
Control Room Monitoring 4K CCTV and operations monitoring arrays in control rooms
Flagship Retail High-impact 4K brand content walls in premium retail environments
