Hikvision DS-D5SC3B-B Wireless Screen Mirroring Dongle (Black)
Hikvision DS-D5SC3B-B Wireless Screen Mirroring Dongle (Black)
Hikvision DS-D5SC3B-B Wireless Screen Mirroring Dongle (Black)
Hikvision DS-D5SC3B-B Wireless Screen Mirroring Dongle (Black)
SKU: DS-D5SC3B-B

Hikvision DS-D5SC3B-B Wireless Screen Mirroring Dongle (Black)

Hikvision

4K Wireless Screen Mirroring Dongle, Black

The Hikvision DS-D5SC3B-B Wireless Screen Mirroring Dongle (Black) (DS-D5SC3B-B) Connect the dongle to any Type-C port on a laptop, tablet, or display interface and instantly stream video wirelessly. The device handles 4K/1080P resolution with H.264 10-bit video encoding and 48kHz 16-bit AAC dual-channel audio. Built-in Gigabit NIC supports network connectivity for content distribution to multiple displays. NFC tags enable one-tap pairing, whilst AES encryption protects transmitted content from eavesdropping.

Highlighted Features

  • Type-C Plug-and-Play: No drivers or external power required when connected to powered Type-C port — works with modern laptops, tablets, and Hikvision displays
  • 4K Wireless Mirroring: 3840×2160 @ 30fps with ≤350ms transmission delay — suitable for presentation slides and video content sharing
  • Dual-Band WiFi Support: 2.4G/5G (802.11a/g/n/ac) with automatic band selection — optimises bandwidth based on environmental interference
  • NFC One-Tap Pairing: ISO/IEC 14443-A, 13.56MHz, 106Kbps — pairs devices by proximity without manual network entry
  • AES Encryption: Protects transmitted video and audio from interception in open conference environments

The DS-D5SC3B-B is the ideal solution for business travellers, educators, researchers, and retail managers requiring a portable wireless casting solution with minimal setup and maximum compatibility.

In stock
£157.40

Secure Checkout

Warranty Protection

Hassle-Free Returns

The DS-D5SC3B-B is a plug-and-play Type-C dongle enabling wireless screen mirroring to Hikvision displays and compatible HDMI screens. It supports 4K resolution at 30 frames per second with transmission latency under 350 milliseconds, suitable for presentation laptops and mobile devices. Dual-band Wi-Fi (2.4G/5G) combined with NFC tap-to-connect streamlines pairing workflow.

Key Features

  • 512MB RAM & 4GB Storage: Embedded system processes wireless decoding and stream routing without external compute dependency
  • Gigabit Network Interface: Built-in 1Gbps Ethernet enables wired failover or networked multi-display distribution
  • H.264 10-bit Video Codec: Professional video compression balances quality and bandwidth — suitable for HD and 4K streaming
  • Dual-Channel Audio: 48kHz 16-bit AAC stereo with automatic level adjustment — natural sound quality for presentations and video conferencing
  • Type-C Dual-Role Power: Accepts 5V/900mA power draw from laptops; supplies 5V/500mA to connected devices for mobile phone charging
  • 60W Laptop Fast Charging: When paired with appropriate AC adapter, supports fast-charging of connected laptops and tablets
  • Compact Form Factor: 189×58×17mm pocket-friendly dongle fits in laptop bags and presentation kits
  • Industrial Temperature Range: 0-40 degrees C operating range suits both heated offices and outdoor event environments
  • Non-Condensing 10-95%RH Humidity: Operates reliably in humid climates and coastal venues without moisture damage

Specifications

Form Factor Type-C plug-and-play dongle
Video Resolution 4K (3840×2160) and 1080P (1920×1080)
Video Frame Rate 30 fps
Transmission Delay ≤350 ms
Video Codec H.264, 10-bit
Audio Codec AAC
Audio Sampling 48 kHz
Audio Bit Depth 16 bit
Audio Channels Dual-channel stereo
Wi-Fi Standards 802.11a/g/n/ac (2.4G/5G)
Wi-Fi Bands 2.4 GHz / 5 GHz dual-band
Encryption AES
NFC Standard ISO/IEC 14443-A
NFC Frequency 13.56 MHz
NFC Data Rate 106 Kbps
Ethernet Interface Gigabit NIC (built-in)
RAM 512 MB
Internal Storage 4 GB
USB Protocol USB 2.0
Power Interface Type-C with CC communication
Power Input 5V / 900 mA
Power Output 5V / 500 mA (phone charging)
Laptop Fast Charge 60 W (with adapter)
Power Consumption 2.8 W
Dimensions 189 × 58 × 17 mm
Weight 90 g
Operating Temperature 0 to 40 degrees C
Operating Humidity 10 to 95% RH (non-condensing)
Colour Black
Warranty 2-year manufacturer warranty

What's in the Box

  • Host (dongle) ×1
  • Manual ×1
  • USB Type-A / Type-C adapter ×1

Application Examples

Business Travel Presentation Executive connects dongle to hotel TV and wirelessly streams quarterly earnings slides from laptop without hunting for HDMI cables
Classroom Lecture Broadcasting Instructor connects dongle to interactive display and mirrors class recording software (OBS) for local students and remote participants
Medical Conference Poster Session Researcher taps NFC sticker on display with smartphone and instantly shares research poster video to conference hall audience
Retail Store Signage Network Manager uses dongle to push promotional video content to multiple in-store displays simultaneously via Gigabit Ethernet
