Hikvision DS-UAC-M1P 32-Mic Array PoE Network Microphone

Hikvision

32-Mic Array PoE Network Microphone

The Hikvision DS-UAC-M1P 32-Mic Array PoE Network Microphone (DS-UAC-M1P) 32-microphone array provides comprehensive 360 degree omnidirectional coverage enabling audio capture from any meeting participant location. 10 metre pickup radius encompasses large meeting spaces, conference halls and broadcast studios without requiring multiple microphone arrays. Exceptional 90dB signal-to-noise ratio exceeds professional broadcast standards, delivering clarity even in acoustically challenging spaces. Advanced echo suppression and anti-reverberation processing compensate for large room acoustic characteristics automatically. PoE power delivery eliminates the need for separate power runs, simplifying installation in retrofit situations.

Highlighted Features

  • 32-Mic Array, 10m Pickup: 32-microphone omnidirectional array with 10m pickup radius captures every voice in large conference rooms
  • 90dB SNR Audio Quality: 90dB signal-to-noise ratio and 105dB dynamic range for professional-grade audio clarity
  • Echo and Reverb Suppression: Advanced AEC, adaptive noise reduction and anti-reverberation for challenging acoustic environments
  • PoE Powered Installation: Power over Ethernet (9–30VDC, 2.4W max) eliminates separate power cabling for clean installations
  • Balanced 600Ω Output: Balanced audio at 600Ω impedance supports transmission runs of 3,000m or more to system processors

The DS-UAC-M1P is the optimal choice for large organisations, broadcast facilities and hospitality venues requiring high-quality centralised audio capture from expansive spaces.

In stock
£273.62

Secure Checkout

Warranty Protection

Hassle-Free Returns

The Hikvision DS-UAC-M1P is a professional-grade microphone array designed for large meeting spaces, conference halls and broadcast environments where distributed audio capture is essential. The 32-element microphone array provides true 360 degree omnidirectional coverage with a 10 metre pickup radius, enabling clear dialogue capture regardless of participant location. PoE power delivery and dual RJ45 audio outputs simplify installation in large facilities.

Key Features

  • 32-microphone array with 360 degree omnidirectional pattern ensures equal sensitivity from all directions
  • 10 metre pickup radius encompasses large conference halls and broadcast studios without supplementary microphones
  • 90dB signal-to-noise ratio provides exceptional clarity in both quiet offices and moderately noisy environments
  • 105dB dynamic range accommodates whispered dialogue through loud speaker presentations without distortion
  • 120dBSPL maximum sound pressure level ensures clean capturing of extremely loud sources
  • 20Hz to 16kHz frequency response captures the full range of human speech and dialogue intelligibility
  • 3000 metre audio transmission distance via balanced line output enables extremely long cable runs without signal degradation
  • Echo suppression prevents feedback when audio is routed back through speakers in the same space
  • Adaptive noise reduction intelligently suppresses ambient air-conditioning, ventilation and traffic noise
  • Anti-reverberation processing compensates for reflective room surfaces automatically

Specifications

Microphone Type 32-element array
Pickup Pattern 360 degree omnidirectional
Pickup Radius 10 metres
sensitivity -36 dB ±1 dB FS
snr 90dB
Frequency Range 20Hz to 16kHz
Dynamic Range 105dB
Max Spl 120dBSPL
Output Amplitude 2.5Vpp maximum
Output Impedance 600 ohm balanced
Audio Transmission Distance 3000 metres or greater
distortion 3% or less
Sampling Rates 16kHz and 32kHz
Processing Features Echo suppression, adaptive noise reduction, anti-reverberation
Power Input PoE 9 to 30VDC
Maximum Power 2.4W
interfaces RJ45 line out, RJ45 line in, DC power input
Operating Temperature -10 to +50 degrees Celsius
Operating Humidity Indoor environments
Dimensions Diameter 250 x height 34.5
Weight 0.74
material Metal and plastic

What's in the Box

  • Microphone
  • Extension cable
  • Quick start guide
  • Installation plate
  • Regulatory information

Warranty

The Hikvision DS-UAC-M1P 32-Mic Array PoE Network Microphone is backed by the 2-year manufacturer warranty, providing peace of mind for professional and commercial installations.
