SKU: iDS-UVC-P32

Hikvision iDS-UVC-P32 2MP 20x Auto-Tracking PTZ Camera

Hikvision

2MP 20× Auto-Tracking PTZ Camera

The Hikvision iDS-UVC-P32 2MP 20x Auto-Tracking PTZ Camera (iDS-UVC-P32) 20x optical zoom with 16x digital zoom provides an equivalent 23.8 to 476mm focal length range, enabling flexible framing from intimate detail to broad room coverage. Sound source localisation via quad microphone array enables intelligent speaker tracking by identifying and following the direction of active speech. Human body following automatically keeps subjects in frame, reducing the need for manual pan-tilt adjustment during presentations. Multiple interface options including HDMI, 3G-SDI, HDBT and Ethernet enable flexible integration into broadcast and professional AV environments. Quad MEMS microphones provide 5 metre pickup radius with sophisticated audio processing including echo cancellation and adaptive noise reduction.

Highlighted Features

  • 20× Optical Zoom: 20× optical zoom (equiv. 23.8–476mm) with sound source localisation for intelligent speaker tracking
  • Quad Microphone Array: Four omnidirectional MEMS microphones with 5m pickup radius and noise reduction for clear audio
  • Multi-Output Flexibility: HDMI, 3G-SDI, HDBT and USB outputs for seamless integration into AV and broadcast systems
  • PoE and 12VDC Power: Dual power options — PoE (IEEE 802.3at) or 12VDC — for flexible installation without dedicated runs
  • Full Pan-Tilt Coverage: Pan ±165° and tilt -90° to +30° for comprehensive coverage of any room configuration

The P32 represents the pinnacle of USB-based PTZ camera technology, combining broadcast-grade optics with professional audio capabilities and intelligent tracking features suitable for large conference centres, broadcast studios and premium video production facilities.

In stock
£1,140.00

Secure Checkout

Warranty Protection

Hassle-Free Returns

The Hikvision iDS-UVC-P32 is a high-end PTZ camera designed for professional broadcast and advanced video conferencing applications. The 20x optical zoom lens delivers exceptional flexibility from wide establishment shots to detailed close-up framing, whilst intelligent auto-tracking features ensure speakers remain optimally framed throughout extended presentations. Quad omnidirectional microphones enable sound source localisation, allowing the camera to pan and tilt in response to speaker location.

Key Features

  • 20x optical zoom lens with equivalent 23.8-476mm range provides unmatched framing flexibility across large spaces
  • Sound source localisation feature automatically identifies and tracks the direction of the active speaker
  • Human body following combined with intelligent tracking keeps subjects perfectly framed without manual adjustment
  • Multiple video outputs support simultaneous routing to recording, streaming, display and broadcast systems
  • RS-232 and RS-485 control protocols including VISCA standard enable integration with professional PTZ control systems
  • 255 preset positions allow rapid switching between configured camera positions and zoom settings
  • Enhanced tilt range of -90 to +30 degrees covers overhead ceiling installations and extreme angle configurations
  • Class 4 PoE power option eliminates need for separate power runs, reducing installation complexity
  • HDBT interface provides long-distance cable runs over standard twisted-pair cabling
  • Professional 2420g weight and larger 206.7mm x 163.3mm x 227.9mm form factor reflect the robust industrial design

Specifications

sensor 1/2.8 inch 2MP WDR CMOS
resolution 1920x1080
Optical Zoom 20x (3.5-70mm varifocal, equivalent 23.8-476mm)
Digital Zoom 16x
Horizontal FOV 78.7 degrees to 4.9 degrees
Vertical FOV 48.4 degrees to 2.8 degrees
Diagonal FOV 87.2 degrees to 5.6 degrees
pan -165 to +165 degrees
tilt -90 to +30 degrees
focus Autofocus and semi-autofocus
wdr 120dB or greater
Microphone Type Quad MEMS
Pickup Pattern 360 degree omnidirectional
Pickup Distance 5 metres
Frequency Response 100Hz to 8kHz
Sensitivity -38±1.5 dBV/Pa
Signal-to-Noise Ratio 64dB
Video Outputs HDMI 1.4, 3G-SDI (SMPTE 424M), HDBT, RJ45 1Gbps
Audio Connectors 3.5mm line in and line out
usb Type-C USB 2.0
Control Protocols RS-232 (VISCA, 9600 baud, 255 presets), RS-485 (HIKVISION/Pelco-D/Pelco-P)
Power Input 12VDC 2.1mm barrel connector or PoE IEEE 802.3at Class 4
Maximum Power 23.1W
Compatible Operating Systems Windows 7, 8, 10, 11; Android 8.1+; Linux 4.14+; macOS 10.12+
Operating Temperature -10 to +45 degrees Celsius
Operating Humidity up to 90% RH non-condensing
Dimensions 206.7 x 163.3 x 227.9
Weight 2.42
material Plastic and metal

What's in the Box

  • Camera
  • Remote control
  • Power adapter with 1.2 metre cable and multi-plug connector
  • Extension cable 3 metres
  • USB 2.0 cable 4.5 metres
  • Mounting bracket
  • Screws
  • Two batteries
  • Regulatory information

Warranty

The Hikvision iDS-UVC-P32 2MP 20x Auto-Tracking PTZ Camera is backed by the 2-year manufacturer warranty, providing peace of mind for professional and commercial installations.
