Lightware MMX8x8-HT440 8x8 Hybrid HDMI/HDBaseT Matrix Switcher

Lightware

8x8 HDMI and TPS Matrix Switcher for conference rooms, featuring 4K/UHD support, advanced audio routing, PoE on TPS ports, and versatile control options.

The Lightware MMX8x8-HT440 is an 8x8 HDMI and TPS Matrix Switcher designed for professional conference rooms, delivering 4K/UHD signal distribution, advanced audio routing, PoE support, and seamless control integration.

Key Features

  • 8x8 Matrix Switching: Four HDMI and four TPS2 inputs with four HDMI and four TPS2 outputs.
  • 4K/UHD & 3D Support: Handles resolutions up to 4096x2160@30Hz and 3840x2160@60Hz.
  • PoE Functionality: 48V PoE available on every TPS port for powering endpoints.
  • Advanced Audio Handling: Balanced Phoenix connectors with embedding and de-embedding.
  • Comprehensive Control: Ethernet, RS-232, USB, IR, Relay, and GPIO with built-in automation.

The MMX8x8-HT440 is the perfect solution for corporate and public sector AV environments requiring reliable 4K signal management, flexible audio routing, and long-distance TPS extension.

In stock
£6,729.60

Secure Checkout

Warranty Protection

Hassle-Free Returns

The Lightware MMX8x8-HT440 is a standalone HDMI and TPS Matrix Switcher specifically designed for professional conference room environments. Featuring four HDMI and four TPS2 (HDBaseT™) inputs with four HDMI and four TPS2 outputs, it delivers seamless AV signal distribution with 4K/UHD support, 3D capability, and full HDCP compliance. With advanced audio routing, PoE functionality, and robust control options including Ethernet, RS-232, USB, IR, and GPIO, the MMX8x8-HT440 provides unmatched flexibility for integrators. Its built-in Event Manager, intuitive control software, and cross-compatibility with Lightware TPS series extenders make it an ideal choice for enterprise-grade AV installations.

Key Features

  • 8x8 Matrix Switching: Four HDMI and four TPS2 inputs with four HDMI and four TPS2 outputs.
  • 4K/UHD & 3D Support: Resolutions up to 4096x2160@30Hz (RGB 4:4:4) and 3840x2160@60Hz (YCbCr 4:2:0).
  • Advanced Audio Handling: Eight balanced 5-pole Phoenix audio connectors with embedding and de-embedding.
  • PoE Remote Powering: 48V PoE available on every TPS I/O port for cost-effective integration.
  • Long-Distance Extension: Signal transmission up to 170m over a single CAT6/7 cable.
  • EDID Management: Factory, custom, and transparent EDID modes for reliable system performance.
  • Versatile Control Options: RS-232, Ethernet, USB, IR, Relay, and GPIO control.
  • Event Manager: Built-in automation feature for triggering actions based on events.
  • Cross-Compatible: Works seamlessly with Lightware HDBaseT™ extenders and compliant displays.
  • Compact & Reliable Design: Rack-mountable, with low latency and zero frame delay switching.

Specifications

Video Inputs 4 × HDMI, 4 × TPS2 (HDBaseT™)
Video Outputs 4 × HDMI, 4 × TPS2 (HDBaseT™)
Maximum Resolution 4096x2160@30Hz (RGB 4:4:4), 3840x2160@60Hz (YCbCr 4:2:0)
Extension Distance Up to 170m over CAT6/7 (with Long Reach mode)
Audio 8 × balanced 5-pole Phoenix connectors (configurable I/O)
Control Interfaces Ethernet (TCP/IP), RS-232, USB, IR, Relay, GPIO
PoE Support 48V PoE on all TPS ports
EDID Management Factory, Custom, Transparent modes with locking capability
HDCP Compliance HDCP 1.4 supported
Event Manager Built-in automation with RS-232, IR, Ethernet, Relay, GPIO triggers
Power Consumption Max. 122W
Mounting Options Rack, furniture, or truss mounting
Compliance RoHS, CE, FCC
