SKU: 91350016

Lightware TPX-2x1-TX20-3x3-RX20 bundle

Lightware

Lightware Taurus TPX transmitter and receiver bundle: UCX-2x1-TPX-TX20 and UCX-3x3-TPX-RX20

The Lightware TPX-2x1-TX20 & UCX-3x3-TPX-RX20 Bundle is an advanced solution for professional AV setups and conference room applications. This bundle is designed to transmit video, audio, USB data, and control signals over a single CAT cable with a range of up to 100 meters. Delivering high-resolution video, reliable signal extension, and robust device control, it ensures seamless integration into modern environments.

Highlighted Features

  • Single CAT Connectivity: Transmits video, USB 2.0/3.1, Ethernet, and control signals over one cable, simplifying installations between the transmitter (TX) and receiver (RX).
  • USB-C Input for 4K Video and Power Delivery: The TX device supports 4K video, audio, data, and power delivery up to 100W via a USB-C connection.
  • Independent USB Host Switching: Enables connection of up to 8 USB devices, split between the TX (4 ports) and RX (4 ports), supporting peripherals like cameras, touch monitors, and speakerphones.
  • HDMI 2.0 Outputs at RX: Provides three independent HDMI 2.0 outputs, allowing flexible multi-display configurations.
  • NIST FIPS 140-2 Certified Variants: Available with Lightware Crypto Core for enhanced data encryption and secure operation.
  • Lightware Advanced Room Automation (LARA): Offers advanced room control and automation capabilities for a highly adaptable AV environment.
  • Custom Welcome Screen: Supports personalized branding and on-screen alerts for professional presentations and notifications.
  • Comprehensive IT Security Features: Includes SSH, SSL, and HTTPS protocols, with support for corporate network standards such as 802.1x for secure connectivity.

Application Benefits

  • Extended Signal Range: Enables transmission of video, audio, and control signals up to 100 meters, eliminating the need for multiple cables.
  • Flexible Device Integration: Supports a wide range of peripherals, including USB cameras, speakerphones, and interactive touch monitors.
  • Secure Networking: Incorporates advanced IT protocols for compliance with modern cybersecurity requirements.
  • Effortless AV Management: Simplifies system setup and operation with centralized control and automation through Lightware's platform.

The Lightware TPX-2x1-TX20 & UCX-3x3-TPX-RX20 Bundle addresses the increasing demand for reliable and adaptable AV solutions, delivering outstanding performance and flexibility in professional environments.

In stock
£4,953.60

Secure checkout

Friendly support

Hassle-free returns

The Lightware TPX-2x1-TX20 & UCX-3x3-TPX-RX20 bundle is an advanced solution for transmitting video, audio, USB data, and control signals over a single CAT cable with a range of up to 100 meters. This system enables high-resolution video delivery, reliable signal extension, and robust device control, making it ideal for professional AV setups and conference room applications.

Key Features

  • Single CAT Connectivity: Transmits video, USB 2.0/3.1, Ethernet, and control signals over one cable, simplifying installations between the transmitter (TX) and receiver (RX).
  • USB-C Input for 4K Video and Power Delivery: The TX device supports 4K video, audio, data, and power delivery up to 100W via a USB-C connection.
  • Independent USB Host Switching: Enables connection of up to 8 USB devices, split between the TX (4 ports) and RX (4 ports), supporting a variety of peripherals like cameras, touch monitors, and speakerphones.
  • HDMI 2.0 Outputs at RX: Provides three independent HDMI 2.0 outputs, allowing flexible multi-display configurations.
  • NIST FIPS 140-2 Certified Variants: Available with Lightware Crypto Core for enhanced data encryption and secure operation.
  • Lightware Advanced Room Automation (LARA): Offers advanced room control and automation capabilities for a highly adaptable AV environment.
  • Custom Welcome Screen: Supports personalized branding and on-screen alerts for professional presentations and notifications.
  • Comprehensive IT Security Features: Includes SSH, SSL, and HTTPS protocols, with support for corporate network standards such as 802.1x for secure connectivity.

Specifications

Compliance CE, UKCA certifications
Operating Temperature 0°C to +50°C (32°F to 122°F)
Operating Humidity 10% to 90%, non-condensing
Cooling Passive design
Warranty 3-year limited warranty
TX Power Supply 160W external power supply
RX Power Supply 80W external power supply
Supported Power Source 100-240V AC, 50/60Hz
AC Power Plug Interchangeable (EU, UK, US/JP, AUS/NZ)
Maximum Resolution 4096x2160@60Hz RGB 4:4:4 (18 Gbps, 600 MHz pixel clock)
Video Inputs USB-C and HDMI (DVI 1.0, HDMI 1.4, HDMI 2.0)
Video Outputs 3 HDMI 2.0 outputs with CEC support
3D Support Yes
TX USB Ports 4 USB-C ports, USB 2.0
RX USB Ports 4 USB 3.1 ports, USB 2.0
USB Host Switching Supports up to 8 devices (4 TX, 4 RX)
Ethernet 10/100/1000 Base-T, PoE
RS-232 Serial Ports 2 TX, 1 RX
GPIO 8-pole Phoenix connector for room automation
Audio Inputs/Outputs Analog output with 5-pole Phoenix connector, de-embedded audio from HDMI
Supported Formats PCM, Dolby Digital, DTS, Dolby TrueHD, DTS-HD Master Audio
Audio Processing Echo cancellation, noise suppression, dereverberation
Environmental Sensors Ambient light, orientation, temperature, humidity, air quality
Occupancy Sensor Available on RX with 24V power
TX Dimensions (UCX-2x1-TPX-TX20) 271 mm x 140.3 mm x 26 mm (10.7 in x 5.57 in x 1.01 in)
RX Dimensions (UCX-3x3-TPX-RX20) 246 mm x 140.3 mm x 26 mm (9.69 in x 5.57 in x 1.01 in)
Weight TX: 1.2 kg (2.64 lbs); RX: 1.1 kg (2.43 lbs)
Custom Welcome Screen Supports corporate logos and on-screen display messages
Advanced IT Security SSH, SSL, HTTPS, 802.1x compliance
Room Automation Lightware Advanced Room Automation (LARA)
